VL-1000 Manford

VL-1000 Manford

SPECIFICATION

X TRAVEL 1,200 mm
Y TRAVEL 610 mm
Z TRAVEL 610 mm
SPINDLE NOSE TO TABLE SURFACE 150 ~ 760 mm
TABLE SIZE 1,300 x 600 mm
T-SLOT (Q’TY X SIZE X DIST) 5 x 18 x 100 mm
MAX. TABLE LOAD 1,200 kgs
CNC CONTROL Mitsubishi / Fanuc / Siemens / Heidenhain
Categories: , , ,

Product description

SPECIFICATION

VL-1000 Manford

X TRAVEL 1,200 mm
Y TRAVEL 610 mm
Z TRAVEL 610 mm
SPINDLE NOSE TO TABLE SURFACE 150 ~ 760 mm
TABLE SIZE 1,300 x 600 mm
T-SLOT (Q’TY X SIZE X DIST) 5 x 18 x 100 mm
MAX. TABLE LOAD 1,200 kgs
CNC CONTROL Mitsubishi / Fanuc / Siemens / Heidenhain
SPINDLE
SPINDLE TRANSMISSION Belt type
SPINDLE TAPER BT40
SPINDLE SPEED 8,000 rpm
SPINDLE MOTOR 7.5 / 11 kW (*)
OTHER ITEMS
ATC CAPACITY ATC Genoa type 20 tools / Arm type 24 tools

* Light bar type machine: optional guarding.

* Spindle motor power depends on motor selection.

*The manufacturer reserves the right to modify the design, specifications, mechanisms, etc. to improve the performance of the machine. Specifications are subject to change without notice.

Spindle motor, CNC Machine, vertical machining center, CNC vertical milling machine
