Product description
SPECIFICATIONS
| SPEC. / MODEL | MEGA BS – 250 HAS | BS 300 HAS | BS 400 HAS | |
| Cutting Capacity | mm | 260 300Wx180H or 280Wx250H |
330 350Wx250H or 300Wx30H |
400 400W x 320H |
| in | 10 12Wx7H or 11Wx10H |
13 13Wx10H or 12Wx12H |
16 16W x 12.5H |
|
| Bundle Cutting | mm | 200Wx140H | 250Wx165H | 320W x 205H |
| in | 8Wx5.5H | 10Wx6.5H | 13W x 8H | |
| Blade Size | mm | 34Wx1.10tx3660H | 34Wx1.10tx3820L | 34 x 1.10t x 4115L |
| in | 1.34W x0.043t x144H | 1.34Wx0.043tx150L | 1.34W x 0.043t x 162L | |
| Blade Speed | M/min | 25,32,42,55,70,80 Variable Speed 20-80 (Opt.) |
25,32,42,55,70,80 Variable Speed 20-80 ( Opt. ) |
25,32,42,55,70,80 Variable Speed 20-80 ( Opt. ) |
| F/min | 82,105,138,180,230,260 Variable Speed 65-260 (Opt.) |
82,105,138,180,230,260 Variable Speed 65-260 ( Opt. ) |
82,105,138,180,230,260 Variable Speed 65-260 ( Opt. ) |
|
| Motor Output | HP | Blade 3;Hyd. 1;Coolant 1/8 | Blade 5 ; Hyd.1 ; Coolant1/8 | Blade 5 , Hyd.1, Coolant1/8 |
| KW | Blade 2.25;Hyd. 0.75;Coolant 0.1 | Blade 3.7 ; Hyd. 0.75 ; Coolant 0.1 | Blade 3.73 , Hyd. 0.75 , Coolant 0.1 | |
| Shipping Volume (L x W x H) | mm | 2120x2090x1500 | 2120 x 2090 x 1600 | 2150 x 2240 x 1770 |
| ft | 6.9×6.8×4.9 | 6.9 x 6.8 x 5.3 | 7 x 7.3 x 5.8 | |
| N.W./G.W. | kg | 1380/1610 | 1410/1640 | 1630/1950 |
| lb | 3036/3542 | 3102/3608 | 3585/4290 | |
NOTE: We reserve the right to modify and improve the specification without notice, the specification shown above is for reference only.
pivot-type-bandsawbandsaw blades band saw for sale portable band saw
FEATURES
- Precise cut off length setting.
- Auto head-elevation and quick approach.
- Nesting fixture.
- Quick-action hydraulic twin -vise (split)3-jaw clamping.
- Unique two-way carriage vise jaw.
- Cutting piece counter.
- Multiple stroke counter.
- LED blade speed display.
- Power-driven saw-band brush.
- Quick adjusting carbide saw-band guides.
- Idle wheel motion detector.
- Hydraulic band-tension control.
- Coolant cleaning flush hose.
- Work-area light.
Standard Equipment
- Tools with tool box: 1 set
- 7 ft .(2M)Long roller table with vertical rollers: 1 set
- Band-Cleaning wire brush: 1 pc
- Band saw blade: 1 pc
- Instruction Manual: 1 copy
Select Equipment
- Automatic chip conveyor.
- Variable blade-speed drive.
- Variable vise pressure system.
- Amplifying valve for auto-adjusting cutting feed-rate.
- Additional spare roller table,wire brush, saw blade, work-area light,etc.
